Key Features
Flexibility
Maximized
One-Cable
Solution
- 10.1인치 및 초고화면비
- Android 13 지원 (지속적인 업데이트 제공)
- MDEP 지원
- USB-C 유선 콘텐츠 공유 / BYOD / 전원 공급
- 초음파 기술 탑재
- 다양한 설치 방식 지원
Specifications
| OS | • Android 13.0 |
| Display | • Screen: 10.1 inch • Display Type: IPS • Resolution: 1280 x 800 • Contrast ratio: 1000:1 • Brightness: 350 cd/㎡ (typical) • Viewing angle (horizontal/vertical): 178°(H)/178°(V) • Touchpoints: Multi-points capacitive touch support • Anti-glare • Anti-fingerprint |
| Audio | • Built-in Ultrasound Unit |
| Physical Interface | • 1 x USB-A port • 2 x USB-C port • 1 x RJ45 port (PoE 802.3af compaint) • 1 x Reset hole • Motion Sensor |
| Installation | • Place on the Table • Mount on the Table • Mount on the Wall |
| Mounting Bracket | • Standard: High Stand • Optional: - Rotatable desktop mount with rotation angle: 90° left and right. - Wall mount |
| Power | • Power Consumption: - Standby: 5 W - Average: 7.3 W - Peak: 15.2 W • Power Adapter: 65W PD • PoE: IEEE 802.3af and above |
| Wireless | • Wi-Fi 6 802.11a/b/g/n/ac/ax • Bluetooth 5.0 |
| Network | • VLAN, 802.1P/Q, and Diffserv • 802.1X, and LLDP-MED • HTTPS |
| Device Management | • Yealink Web Portal • Yealink Device Management Platform • Teams Admin Center • Zoom Device Management |
| Package | • CTP25 • 7.5m Ethernet Cable • 1.2m USB-C Cable • PD Power Adapter (65W) • Screwdriver • High Stand • Cable Management Cover • M3 Screws * 10 • Cable Ties * 5 • Quick Start Guide |
| Environment | • Operating Temperature: -10 to +45°C • Storage Temperature: -30 to +70°C |
| Dimensions &Weight | • Box: - Dimension: 286 × 198 × 140 mm - N.W/CTN: 1.578 kg - G.W/CTN: 1.846 kg • Canton: - Dimension: 725 × 410 × 300 mm - N.W/CTN: 18.478 kg - G.W/CTN: 19.798 kg - Quantity: 10 pieces • CTP25: - Dimension: 242.95 × 27.50 × 161.95 mm - Weight: 0.683 kg |
